Product data sheet
Valve
A9104-0804-1322-XX,
May 30, 2025
Seat Valve electrically force-controlled
Series A91-0804-Cryo FL
Valve A9104/0804/1322-XX DC
2/2-Way Solenoid Valve Made of Stainless Steel – Long-Spindle Design for Liquefied Gases This solenoid valve is specifically designed for use with liquefied gases such as LN2 (nitrogen), LCO2 (carbon dioxide), and—when selecting option F—also for liquid oxygen (LOX). The long-spindle design allows optimal insulation of the valve body. Since the solenoid actuator is positioned at a sufficient distance from the cold source, heat input remains negligible. Additionally, this valve design is compatible with EEx solenoids, making it suitable for use in Ex-Zone I. Our cryogenic valves are specially developed for applications requiring media temperatures as low as -196 °C.
For more information follow this link:
Valve A9104/0804/1322-XX DC
Datasheet explicit
Version | A | |
Type of valve | 91 | Seat Valve electrically force-controlled |
Connection type, valve seat | 04 | DN32 32mm |
Kv-value (Δp = 1 bar H₂O) | ||
Housing | 08 | AISI 316 Ti - 1.4571(81) |
Sealing | 04 | PTFE |
Voltage type | 1 | DC |
Solenoid power | 32 | 30W |
Protection class | 2 | IP65 |
Valve option | XX | normally closed + Distance unit + free of Oil/grease + dry |
System pressure | 0 - 16 bar | |
Valve type | 12V, 24V, 48V, 110V, 120V, 220V, 230V, DC | |
Temperature Medium | from -196 °C to 80 °C | |
Temperature Environment | from -40 °C to 40 °C | |
Mounting position | ||
Specific use case | Closed system (includes open system) | |
scope of delivery | 1 valve, 1 connector FormA EN175301-803/A | max. current 10A | 4x90°| IP65 when installed | connectable cables Ø 5-10 mm max.1.5mm² | 1 Solenoid .322 Steel K05132XX | 100% duty cycle | rotatable 360° | |
Valve option | XX | normally closed + Distance unit + free of Oil/grease + dry |
Description | Valve opens with continuous voltage | Distance unit between valve body and actuator | Innerparts dry and specially cleaned | |
REACH-RoHS conformity | REACH Yes | RoHS Yes | |
Net weight | 10.2 kg | |
Switching time (at 6 bar gas) | On: 1000 ms | Off: 1000 ms | |
Customs export | Customs tariff number 84818073; Country of origin Germany; ECCN (US): N; AL: N |
